ABOUT US
The NMB SPLICE-SLEEVE® system is a proven method for connecting precast reinforced concrete structural members.
This method uses a cylindrical shaped steel sleeve filled with a Portland cement based non-shrink high-early strength grout.
Reinforcing bars to be spliced are inserted into the sleeve to meet approximately at the center of the sleeve.
The interior of the sleeve is then filled with SS MORTAR® grout.
General Information
Here's why:
Traditional
Corrugated Pipes
Using
NMB Splice Sleeve System
VS
4 Workers vs 3 Workers
1 Column,
12 Size 40 Rebars
3 Bags of SS Mortar
14 Bags of Mortar
Total
Mixing and Preparation = 21 Mins
+
Grouting of Splice Sleeves = 12 Mins
Total
Mixing and Preparation = 2.3 Hours +
Filling corrugated pipe = 2 Hours
Total
Man-hours Required: 0.55
Total
Man-hours Required:
4.3
*Disclaimer: Data shown is only an estimate and are meant to be indicative only.
Productivity - Projects Finished on Time
Manpower Cost Savings - Lower Man-hours Required
Buildability - Bonus Points for Buildable Design Scores
OUR PRODUCTS
Super UX Sleeve
(Precast Construction)
The Super UX sleeve is approved for Class SA connection in Japan which exceeds Type 2 in the U.S and conforms to ISO 15835 under S1 Category.
The Super UX sleeve is available for rebar sizes of D16 to D41.
NX II SLEEVE
(Precast Construction)
The NX II is categorized under Class A connection in Japan which is equivalent to Type 2 in the U.S and conforms to ISO 15835 under S1 Category.
The NX II is available for rebar sizes of D16 to D22.
NMB SLIM-SLEEVE
(Cast-in-place construction)
The Slim sleeve was developed for cast in place applications. It can be used to connect cages, precast beam to beam or column to beam for horizontal/ vertical sliding connections.
The Slim sleeve is available for rebar sizes of D16 to D51.
SS MORTAR
The SS Mortar® grout is a non-shrink, high-early-strength cement grout developed for use with the NMB Splice Sleeve System.
SS Mortar® is certified by ICC-ES which achieves the requirements for use in the sleeves under ICC-ESR 3141. The NMB Splice-Sleeve System® utilizes two basic grouting methods namely, the Post-Grout method and the Pre-Grout method.
Specially engineered to be highly flowable, this grout can fill the chamber of the sleeve thoroughly. It comes pre-mixed with selected blended materials for easy site management.
Features
Tolerance absorbance for misaligned bars
No shrinkage or elongation of sleeves
Ease of connection
PROJECTS USING SPLICE SLEEVE
CAPITAGREEN
BCA Construction Productivity Platinum Award
Australia 108
(Melbourne)
CAPITAGREEN
Melbourne, Australia
JTC Space @ Tampines
Pinnacle@Duxton
Pinnacle @ Duxton
JTC SPACE @ Tampines
